RF Cable Assemblies

Types of Cable Assemblies

  • SMA Cable Assemblies
    SMA Cable Assemblies
    SMA Cable Assemblies feature ultra-miniature threaded connectors with 50Ω impedance, supporting DC-30GHz applications. They provide low VSWR, high mating durability, and precise signal integrity for compact microwave systems and aerospace instrumentation.
    Read More

    SMA Cable Assemblies

Applications of RF Cable Assemblies

RF cable assemblies are essential for high-frequency signal transmission across multiple industries, offering reliable connectivity and performance. They are widely used in the field of telecommunications, aerospace & defense, test & measurement, medical & industrial IoT, automotive & EV and so on.


RF cable assemblies play a critical role in modern communication systems, ensuring high-speed, low-loss signal transmission. Key telecom applications include:

1) 5G/6G Infrastructure

  • mmWave Deployment: Low-loss assemblies (SMA/SMP) for 24-40GHz small cells

  • Massive MIMO: Phase-matched cables (±2°) for antenna arrays


2) Fiber-Wireless Integration

  • FTTA (Fiber-to-Antenna): Hybrid RF/optical cables for distributed antenna systems

  • CPRI Interfaces: Precision 50Ω assemblies for baseband unit connections


3) Backhaul Networks

  • Microwave links using flexible low-PIM cables (<-150dBc)

  • Weatherproof IP67-rated assemblies for outdoor installations


4) Indoor Coverage

  • DAS (Distributed Antenna Systems): Slim RG-174 cables for building penetration

  • IoT Gateways: Miniature MMCX/IPEX assemblies for compact devices



Features of RF Cable Assemblies

  • Precision Engineered Performance

    RF cable assemblies deliver ultra-low loss and stable 50 ohms/75 ohms impedance from DC to 67GHz for critical signal integrity in 5G and aerospace systems.


  • Ruggedized Reliability

    Featuring military-grade quad-shielding and strain relief, these assemblies withstand extreme temperatures (-55°C to +200°C), vibration, and repeated flexing for harsh environment deployment.


  • Custom Configuration Flexibility

    Available in any length with SMA connectors or other connectors, including phase-matched pairs and waterproof variants for bespoke radar, test equipment and satellite applications.

Why Professionals Choose Our RF Cable Assemblies

  • Low-Loss Signal Transmission

    Ensures high-frequency signal integrity over long distances with minimal attenuation. Low-loss dielectric materials (e.g., foamed PE/PTFE) with typical insertion loss, precision impedance control (50Ω/75Ω) to minimize reflection and multi-layer shielding (foil + braid) for >90dB EMI suppression.

  • Customizable Flexibility

    Adapts to diverse application needs. Cable length can be customized from 0.1m to 100m, multi-interface options (SMA, MCX, N, SMP, BNC and other series combinations) and specialized versions can be customized.

  • Optimized Electromagnetic Compatibility (EMC)

    Ensures signal purity by suppressing interference. Triple shielding (foil + braid + drain wire) with >100dB shielding effectiveness, Low PIM and enhanced grounding 360° conductive gasket design.

RF Cable Assemblies FAQs

What are RF cable assemblies, and what are their key features?

RF Cable Assembly refers to a complete transmission line consisting of a coaxial cable with connectors (e.g., SMA, N-type, BNC) attached to both ends. These assemblies are designed to ensure reliable signal transmission in high-frequency applications while minimizing signal loss, interference, and impedance mismatch.

Key Components include:

  • Coaxial Cable (e.g., RG-58, LMR-400, semi-rigid).

  • RF Connectors (e.g., SMA, MCX, MMCX, N, BNC, TNC, SMP).

  • Optional Features: Strain relief, overmolding, waterproofing.


The key features of RF cable assemblies include high frequency performance, low signal loss, precision impedance matching, shielding effectiveness, durability, flexibility, phase stability, custom lengths & connectors and so on.

What is a coaxial cable, and what are its common types?

A coaxial cable is designed to transmit high-frequency electrical signals with minimal interference. Its structure consists of:

  • Inner Conductor: Solid or stranded copper (or copper-clad steel).

  • Dielectric Insulation: PTFE (Teflon), PE (polyethylene), or foam materials.

  • Outer Shield: Braided copper, aluminum foil, or solid metal (for semi-rigid cables).

  • Jacket: PVC, PE, or LSZH (low-smoke zero-halogen) for environmental protection.


Common Types by Impedance

(1) 50Ω Coaxial Cables

Applications: RF communications, cellular systems, test equipment, Wi-Fi, and radio antennas.

  • RG-58: Flexible, thin (5mm), used for short-range RF connections (e.g., CB radios, test leads).

  • RG-213: Thicker (10.3mm), higher power handling, for base stations and amateur radio.

  • LMR-400 (Low Loss): Superior shielding, replaces RG-8; ideal for long-distance RF (e.g., GPS, 5G).

  • Semi-Rigid Cables (e.g., UT-141): Solid copper shield, fixed installations (microwave systems).


(2) 75Ω Coaxial Cables

Applications: Video signals (TV, CCTV), satellite TV, and digital broadcasting.

  • RG-6: Dual-shielded, widely used for cable TV/SATV and broadband.

  • RG-59: Thinner than RG-6, for short-distance analog video (e.g., CCTV cameras).

  • RG-11: Low-loss, long-distance backbone cabling (e.g., CATV trunk lines).
